PLA Series – Flex-Fitter™ Area Light
CERTIFICATIONS / RATINGS
• UL Certified
• DLC 5.1 Premium
• FCC
• ROHS Compliant
• IP65
FEATURES AND BENEFITS
• The Flex-Fitter is modular, adjustable and adaptable area luminaire.
• Available in four lumen packages – all include the slip-fitter hardware.
•Mounts to square and round poles as well as mast arms and wall surfaces.
• Designed and built with high-performance materials to withstand the elements.
• Engineered parking lot system provides year-after-year performance and
reliability.
• 0-10v dimming
• DLC 5.1 Premium listed.
APPLICATIONS
Anywhere overhead pole lighting is required, such as retail centers, industrial parks, schools and universities, public transit and airports, office
buildings and medical facilities.
DOWNLOADS
SPECIFICATIONS
| Voltage | 120v-277vAC / 277-480vAC |
| Wattage | 60w / 100w / 150w / 200w / 300w / 400w |
| Color Temp | 5000 (standard) / 4000 (optional) Kelvin |
| Housing | Die-cast aluminum |
| Color | Bronze (custom colors by request) |
| Lens | Polycarbonate |
| Distribution | Type II / III / IV / V (type III standard) |
| Lifetime | 50,000 hrs L80 |
| CRI | 70 |
| Ambient Temperature | -30°C (-22°F) to 45°C (113°F) |
| Power Factor | 0.95 |
| Protection | IP65 |
| Warranty | 5 Year Limited Warranty |
LUMENS
| 60w | 100w | 150w | 200w | 300w | 400w |
| 8,700 lm | 13,000 lm | 21,000 lm | 27,000 lm | 42,100 lm | 56,800 lm |
See specification sheet for product ordering selection, mounting options, weights and dimensions.
